ESP32-S3 2.06inch AMOLED Touch Watch Development Board, with 410×502 Pixels 16.7M Color Display, Integrate 2.4 GHz Wi-Fi and BLE 5, Support Offline Voice Recognition and AI Speech Interaction

ESP32-S3 2.06inch AMOLED Touch Watch Development Board --Equipped with ESP32-S3R8 Xtensa 32-bit LX7 dual-core processor, up to 240MHz main frequency --Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE), with onboard antenna --Built in 512KB of S-R-A-M and 384KB ROM, with onboard 8MB PSRAM and an external 32MB Flash memory --Type-C connector, improving device compatibility, easier to use --Onboard 2.06inch AMOLED capacitive touch display for clear color picture display, 410 × 502 resolution, 16.7M color --Built-in CO5300 display driver and FT3168 capacitive touch chip, using QSPI and I2C communication respectively, effectively saving the IO resources --Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gesture, counting steps, etc. --Onboard PCF85063 RTC chip, powered by Lithium battery through AXP2101 chip for uninterrupted power supply --Onboard PWR and BOOT programmable buttons for easy custom function development --Onboard 3.7V MX1.25 Lithium battery recharge/discharge header --Onboard reserved pads of 1 × I2C, 1 × UART and 1 × USB interfaces, for connecting peripherals and debugging --Onboard TF card slot for extended storage and fast data transfer, suitable for applications such as data recording and media playback, simplifying circuit design --Adopts AXP2101 IC for efficient power management, supports multiple voltage outputs, battery charging, battery management, and battery life optimization, etc. --Comes with a custom-designed case with a smartwatch-like appearance, making it ideal for prototyping and functional verification of wearable applications Package Content ESP32-S3-Touch-AMOLED-2.06 x1 Watch straps ×1MX1.25 Lithium battery ×1 NOTE: Online Development Resources and Technical Support are provided, please feel free to contact us if you have any problem!

• ESP32-S3 2.06inch AMOLED Touch Watch Development Board equipped with ESP32-S3R8 Xtensa 32-bit LX7 dual-core processor, up to 240MHz main frequency. Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE), with onboard antenna
• Built in 512KB of S-R-A-M and 384KB ROM, with onboard 8MB PSRAM and an external 32MB Flash memory. Onboard TF card slot for extended storage and fast data transfer, suitable for applications such as data recording and media playback
• Onboard 2.06inch AMOLED capacitive touch display for clear color picture display, 410 × 502 resolution, 16.7M color. Built-in CO5300 display driver and FT3168 capacitive touch chip, using QSPI and I2C communication respectively
• Onboard ES8311 audio codec chip and ES7210 echo cancellation circuit. Meet daily audio application scenarios, Onboard Dual Digital Microphones Array. Supports offline voice recognition and AI Speech Interaction
• Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gesture, counting steps, etc. Onboard PCF85063 RTC chip, powered by Lithium battery (Included) through AXP2101 chip for uninterrupted power supply. Onboard 3.7V MX1.25 Lithium battery recharge/discharge header
• Note: ESP32-S3 2.06inch AMOLED Touch Watch Development Board is not a standard, pre-configured smart watch. It is a DIY module that requires the customer to develop their own application, supports ESP-IDF and its ecosystem, and can be developed using ESP-IDF or arduino-esp32 Core
